Description
Model GM-C803-001 GM-C803-005
Output Power <1mW <5mW
Wavelength 532nm
Dimension ∮8X30.5+/-0.5mm(without circuit)
Beam Mode TEM00
Operation Mode CW
Beam Diameter <1.5mm at aperture
Beam Divergence <1.2mrad
Warm Up Time < 3 sec.
Optimum Operating Temperature 20~30℃
Operating Current <300mA
Lift Time(MTTF) >3000hr
Input Voltage 3V
Housing Brass
Output Power <1mW <5mW
Wavelength 532nm
Dimension ∮8X30.5+/-0.5mm(without circuit)
Beam Mode TEM00
Operation Mode CW
Beam Diameter <1.5mm at aperture
Beam Divergence <1.2mrad
Warm Up Time < 3 sec.
Optimum Operating Temperature 20~30℃
Operating Current <300mA
Lift Time(MTTF) >3000hr
Input Voltage 3V
Housing Brass
