Description
Wavelength 515 +/-10nm
Output Power <5mW(4+/-1mW) / <1mW (0.8+/-0.2mW)
Module Dimensions 12 x 17.5 mm (without PCB)
Power stability@30min <+/-5%
Output Mode CW
Beam Mode TEM00
Beam Diameter <2mm at aperture
Beam Divergence <1 mrad
Operating Temperature range -10~50℃
Storage Temperature -10~70℃
Operating Current <300 mA
Applied Voltage 3~5 V
Life time >5000hr
Housing Aluminum
Output Power <5mW(4+/-1mW) / <1mW (0.8+/-0.2mW)
Module Dimensions 12 x 17.5 mm (without PCB)
Power stability@30min <+/-5%
Output Mode CW
Beam Mode TEM00
Beam Diameter <2mm at aperture
Beam Divergence <1 mrad
Operating Temperature range -10~50℃
Storage Temperature -10~70℃
Operating Current <300 mA
Applied Voltage 3~5 V
Life time >5000hr
Housing Aluminum
